3" / 3.5" Speakers

  • B33 3.5 inch Full Range Speaker
  • B33 3.5 inch Full Range Speaker
  • B33 3.5 inch Full Range Speaker
  • B33 3.5 inch Full Range Speaker
  • B33 3.5 inch Full Range Speaker
  • B33 3.5 inch Full Range Speaker
B33 3.5 inch Full Range SpeakerB33 3.5 inch Full Range SpeakerB33 3.5 inch Full Range SpeakerB33 3.5 inch Full Range SpeakerB33 3.5 inch Full Range SpeakerB33 3.5 inch Full Range Speaker

B33 3.5 inch Full Range Speaker

  • 3.5 inch
  • Normal Power : 30W
  • Max Power : 100W
  • Full Range Speakers
  • Product description:
  • INQUIRY

Welcome

We are very apprecitated that you are interested in our products.This product is a full-range Speaker

Install

This product can be used as a car mid-to high frequency , or it can be used as a central speaker alone.
During the installation process, please pay attention to the insulation of the wiring .
The product contains storng magnets, please pay attention to the adsorption of magnetically conductive materials such as iron filings and be careful of pinching.
The mounting screws are firm and not loose.
The product has a high pitched diffuser.please do not press hard.

Debugging

When this product is used as a single central speaker, the cut off point of the mid -low frequency should not be lower than Hz, When used as a three-way Mid-range and high pitch, it is recommended that the cut frequency is not lower than 650Hz



item
value
Norminal Impedance
4ohm
Frequency Range
150Hz-19kHz
Nom Power RMS
30W
Max/Peak Power
50W/100W
Come material
Raw Wood Pulp Fiber
Qms
6.37
Qes
0.622
Qts
0.565
Size
98mm
Magnet Size
53mm
Sensitivity
86dB
Mounting depth
39mm
Mounting hole
78mm
Warranty
2 years
Place of Origin
China
Guangdong
Brand Name
Guangzhou
