B350 Mid- Tweeter

Material of Speaker ----------------Paper Pulp

Nominal Impedance ---------------8ohm

Recommended Frequency  Range --------100Hz- 19 kHz

Short Term Power Handling ------------300W

Long Term Power Handling ------------100W

Sensitivity 1V/m---------------87dB

Voice Coil Diameter-------------25.5mm

Voice Coil  Height -----------12mm

DC  Resistance of Voice Coil Re------------5.6 ohm

Voice Coil Inductance Q1kHz Le-------------1.08mH

Force Factor BI------------------------4.654 T-M

Free Air Resistance Fo----------------127 Hz

Equivalent Volume Suspension Vas --------11.105

Mechanical Q Factor  Qms----------1.053

Electrical Q Factor Qes------------0.962

Total Q Factor  Qts------------0.108%

Mms--------------------------3.896g
